Smart Home Control Panel, Zigbee and Matter Compatible, Device Control and Energy Monitoring with LCD Screen and Camera Streaming

Aqara's Panel Hub S1 Plus EU is a high-end wall panel that centralises control of your connected home. Thanks to its 6.9-inch touch screen, dashboard functions, Zigbee, Matter and dual-band Wi-Fi compatibility, it lets you control your devices, scenes, cameras or monitor energy consumption from a single, elegant and customisable control point.

• 2-in-1 wall-mounted control panel with integrated switches
• Touch control and customisable dashboards
• Zigbee hub function and integrated Matter bridge
• Live video streaming from Aqara cameras and doorbells
• Daily energy consumption monitoring
• Screen activation by proximity detection up to 2.5 metres away

Technical specifications of the Hub Panel S1 Plus EU Aqara

• Dimensions: 172 × 86 × 42.2 mm (6.77 × 3.39 × 1.66 in.)
• Screen resolution: 1440 × 720
• Wireless protocols: Wi-Fi 2.4GHz/5GHz, Zigbee 3.0, Bluetooth
• Input power: 200-240 V, 50/60 Hz, Max 8 A (resistive load)
• USB-C input: 5V 2A
• Load rating: 1 channel up to 300W; 2 channels: 200W + 100W
• Operating temperature : -10 °C ~ 40 °C
• Operating humidity: 0 ~ 95% RH, non-condensing

The Aqara S1 Plus panel is the ideal solution for centralising all your home automation controls. Intuitive, scalable and fully customisable, it fits perfectly into any room and transforms your connected home experience.

Notes :

• The 6 built-in wireless switches may not be exposed in all third-party Matter ecosystems, but are well supported in Aqara Home.
• For full Matter compatibility, a Matter controller from the correct ecosystem is required.
• Only Aqara camera devices are supported for video streaming, and only one video stream can be displayed at a time.
• Up to 10 customisable dashboards with up to 60 cards per dashboard (devices or scenes), synchronisable with Aqara Home.
• Proximity activation distance adjustable to 10 levels, available only in Aqara Home.
